Article number: 706249* *ASSA cylinders article numbers consist of a six numbered code followed by a three numbered variation code followed by a three numbered surface treatment code. Only a full article number is valid ex. XXXXXX-YYY-ZZZ. Application WP is ASSA's new range of high-tech padlocks designed for harsh weather conditions around the world. The locks have unique characteristics to withstand the most extreme rigors of time without being affected. WP stands for Weather Proof.   With the sealing O-rings at the shackle, the cylinder and the keyway an ASSA WP padlock is weather proof. This means that the locks can hang out in the rain and wind, the inside is just as dry. The lock also has a good resistance to corrosion and meets the highest standards for corrosion resistance. Features Shackle in Boron steel Padlock body in steel WP2 and hardened steel WP3 and WP4 Chrome finish IP68 Rated Included in the insurance companies approved lock unit Designed for alternative cylinder types Fits into Master Key Systems Sealed lock cylinder Key -locking design Operating Temperatures: -40° F to +130° F and -40º C to +80° C Comes with alternate shackle heights Function ASSA WP padlock is ideal for use with CLIQ or CLIQ Remote technologies. With CLIQ you combine mechanical lock technology with an electromechanical encrypted code. CLIQ Remote is unique and can be used anywhere, even when the padlock is placed in harsh environments. It is also possible to get ASSA WP padlocks with other Master key systems from ASSA. Finish Polish Chrome (211)   Weather resistance   IP68 – fully dust tight, withstands continued immersion in water   IP (International Protection) indicate how well an item is protected against dust and water ingress. The first digit indicates the degree of protection provided against the intrusion of foreign objects and dust, the second digit indicates water resistance. The IP68 designation awarded to ASSA ^® WEATHER PROOF (WP) padlocks indicates a hermetic seal. Warranty ASSA warrants its padlocks against defective workmanship or wear under normal use and with regular maintenance.

Article number: 709141* *ASSA cylinders article numbers consist of a six numbered code followed by a three numbered variation code followed by a three numbered surface treatment code. Only a full article number is valid ex. XXXXXX-YYY-ZZZ. Application For use with ASSA Modular and Connect lockcases.   Specification The cylinder is fixed with four high security hardened steel screws, supplied with the accessory set. ASSA accessories must be used.   Surface treatment Satin Chrome (213) Polish Chrome (211) Polish Brass (220) Satin Brass (221) Brown oxid (044) Warranty ASSA warrants its cylinders against defective workmanship or wear under normal use and with regular maintenance.

Article number: 820034* *ASSA cylinders article numbers consist of a six numbered code followed by a three numbered variation code followed by a three numbered surface treatment code. Only a full article number is valid ex. XXXXXX-YYY-ZZZ. Application For use with locks accepting Euro profile cylinders. Specification Cylinders are supplied with fixing screw. Standard lengths are 61mm and 71mm Extended length cylinders are also available. Decorative and security accessories are available: see Door Furniture section. Optional functions: A1 - Classroom, clockwise B1 - Classroom, anticlockwise C1 - Clutch DA1 - Dual action The M20 high security Euro cylinder range is also available offering high resistance to snapping. Surface treatment Satin Chrome (213) Polish Chrome (211) Polish Brass (220) Satin Brass (221) Brown oxid (044)   Warranty ASSA warrants its cylinders against defective workmanship or wear under normal use and with regular maintenance.

Article number: - Master key: 820001 Sub master key: 820002 ´ Key ordered afterwards: 820003 All ASSA keys are manufactured from the highest quality nickel silver material and the key's rounded back facilitates gives smooth operation and minimizes wear. Benefits Two different key cuts designed to operate two independent locking mechanisms Innovative key design protected by international patents Patented key control offers the ultimate in high security Top cuts can be generated on standard, quality code cutting equipment ASSA's generous keying capabilities allow vast amount of change keys under a single master key Every key is unique worldwide Only one physical key profile EN1303:2005 Key related security grade 6  Technical Information High quality nickel silver material Maximum adjacent cut is 5 and 2 alike codes in a row may be used Nine different top code heights

Free spinning locker hasp for doors < 22 mm

ASSA öppnaknappar används på insidan av låsta dörrar, där de med en enkel knapptryckning låser upp dörren och, i förekommande fall, förbikopplar dörrlarmet. Öppnarknappen ansluts till undercentralen eller DAC. Öppnarknappen har en tydlig symbol i form av en nyckel, för att beskriva funktionen. TKN01 är gjord för utanpåliggande montage.

Article number: 704213* *ASSA cylinders article numbers consist of a six numbered code followed by a three numbered variation code followed by a three numbered surface treatment code. Only a full article number is valid ex. XXXXXX-YYY-ZZZ. Application Green stripes indicate Security Grade 3 to BS EN 12320. Specification Padlock body of extruded brass, black chrome plated. Shackle of rustproofed hardened steel, 8mm or 10mm diameter. Drainage holes in the padlock body prevent freezing. No external screws or rivets. Tensile strength over 1½ tons.   Finish Black Chrome (017) Warranty ASSA warrants its padlocks against defective workmanship or wear under normal use and with regular maintenance.
