ABLOY PROTEC

The unique, patented construction of the ABLOY^® PROTEC rotating disc cylinder makes it virtually pickproof. Keys and discs use a new principle where cuts are made on two different radii. In addition, the return bars block the discs at 90° if the key and cylinder combinations are not identical.

The ABLOY^® PROTEC cylinder not only meets but exceeds international standards for high security including UL 437 and EN 1303.
1.97 billion different key combinations per keyway make it possible to create extensive master-key systems that fulfil your precise specifications.

Features

• New patented rotating disc mechanism
• Unique disc blocking system DBS^™ by return bars
• New cylinder construction makes ABLOY^® PROTEC virtually pickproof
• No springs, pins or other parts to wear out
• Superior master-keying possibilities
• Smooth, durable and reliable operation that is resistant to both dirt and freezing
• Strict key control: duplicate keys only with the key card
• Key blanks protected by world-wide patents
• Keys are cut using a dedicated ABLOY^® key-cutting machine
• All metal key
• Convenient reversible key
• Colour insert for easy identification
• The key meets no resistance when it is inserted
• Virtually no key wear: no broken, bent or worn keys
• Key cuts on two radii (2RTM)

2RTM
Unique, patented cutting of keys on two radii (2RTM system) ensures keys can only be cut on a dedicated key cutting machine.

DBS^™
DBS stops any attempt to manipulate discs individually in the cylinder by locking the discs together as one solid package, thereby eliminating any attempts to manipulate or bypass the cylinder.

The exceptional master-keying capabilities and excellent local service and support make ABLOY^® PROTEC the ideal choice for hospitals, universities and large industrial and government complexes.
Retrofit cylinders can be supplied to fit most applications world-wide.

• Australian oval cylinders
• ANSI cylinders
• DIN cylinders
• Scandinavian cylinders
• Tubular deadbolts
• Finnish cylinders
