    Henderson Flexirol 500

    • Residential
    • Hospitality
    • Retail
    • Office and enterprise
    • Entertainment and public facilities
    • BIM and specification
    • Henderson

    Flexirol is a unique system ideally suited to large doors which require high performance as well as an attractive finish. It’s an ideal product for hotels, offices, conference centres, shop fronts and showrooms where durability and design are paramount. The product caters for wooden or metal doors fabricated from either angle frame or box section with aluminium extrusion. The track can be soffit fixed or face fixed for flexibility of installation.

    For top hung sliding timber and metal doors. Max. 500kg.

    • Ideally suited to hotels, conference centres, shop fronts, showrooms or any site requiring high performance and an attractive finish.
    • Designed for straight sliding doors in timber, metal or glass.
    flexirol

    Flexirol 500

    flexirol

    1 of 4

    Fire Rated No
    Location Internal
    Application Residential, Commercial
    Max. Door Weight 500kg
    Door Material Wood, Metal
    Max. Door Width 6000mm
    Door Material Wood or Metal
    Situation Interior
    Application Residential/Commercial
    Door Thickness Range 40 - 100mm
    • For wooden or metal doors (either angle frame or box section) weighing up to 500kg
    • Ideally suited for hotels, conference centres, shop fronts and showrooms which require high performance
    • Track can be soffit fixed or face fixed for flexibility of installation
    • PC Henderson Flexirol 500 Data Sheet(PDF, 404 KB)
    • henderson-accessories-list.pdf(PDF, 614 KB)
    • henderson-top-hung-index-page.pdf(PDF, 32 KB)
    • henderson-430-431-locking-bar-fitting-instructions.pdf(PDF, 34 KB)
    • henderson-aluminium-bolt-333-fitting-instructions.pdf(PDF, 66 KB)
    • henderson-aluminium-bolt-454-fitting-instructions.pdf(PDF, 66 KB)
    • henderson-flushbolt-77-for-industrial-use-fitting-instructions.pdf(PDF, 37 KB)
    • henderson-flushbolt-78-for-industrial-use-fitting-instructions.pdf(PDF, 41 KB)
    • henderson-industrial-data-sheets-components.pdf(PDF, 302 KB)
    • henderson-industrial-data-sheets-straight-sliding-section.pdf(PDF, 2 MB)
    • henderson-residential-sliding-and-folding-door-hardware.pdf(PDF, 7 MB)
    • henderson-product-range-for-sliding-and-folding-doors.pdf(PDF, 6 MB)
    ItemPart numberPackaging
    Flexirol Straight Sliding Hanger Corner Plate Fix Timber DoorH556/52
    Flexirol Straight Sliding Hanger Surface Mount Plate Timber DoorH556/57
    Pacer Pivot Set Timber DoorH21/550PTrade
    Track Jointing StripH500JSTrade
    Flexirol Track 2.0m - AnodisedH550/2000ATrade
    Flexirol Track 3.0m - AnodisedH550/3000ATrade
    Flexirol Track 4.0m - AnodisedH550/4000ATrade
    Flexirol Track 6.0m - AnodisedH550/6000ATrade
    Flexirol Cross Joint IntersectHKW/550Trade
    Flexirol 'T' IntersectHTW/550Trade
    Flexirol Face Fix BracketH1A/550Trade
    Flexirol Soffit Fix BracketH3S/550Trade
