Pacer Sliding Kit
Features and Specifications
- Aluminium mill finish track in 2000, 2500, 3000, 3500, 4000, 5000 & 6000mm
- Anodised aluminium track in 2000, 2500, 3000, 3500, 4000, 5000 & 6000mm
- AN Brackets Face fixed bracket 1B Jointing bracket
- Hangers Angle plate fixing hanger for wooden doors
- Hanger for angle frame metal doors 56B Hanger for box frame metal doors
- Concealed fixing hanger for wooden doors, aluminium doors or metal doors
- Guides Floor mounted guide for wooden, aluminium or metal doors
- Concealed fixing guide for wooden or aluminium doors
- Guide for angle frame metal doors
- Guide for box frame metal doors
- Guide Channel Brass guide channel available in 1500 and 3000mm lengths
Application:
- For wooden and metal sliding doors weighing up to 200kg
- Wooden doors can be either solid or glazed and metal doors can be of angle or box section
- Ideal for shop-fronts, offcies and other stylish interiors
Certification:
- BS EN 1527:1998
