  • Doors & gates
  • ASSA ABLOY Mercor Doors

Multi-family doors

  • Mercor Doors

Our offer includes doors dedicated to residential buildings. Raptor multi-family doors are an ideal solution for multi-family housing and modern hotel facilities.

A door leaf with a panel structure made of 1 mm galvanized steel sheet, joined using the clinching method, filled with mineral wool and eqipped with security bolts. 60mm thick door leaf, reinforced with galvanized steel C-bars. Corner frame made of galvanized steel sheet 1,5 mm thick, without visible welds. Adjustable steel hinges powder painted in any colour from the RAL palette. Doors with RC3 anti-burglary class.

Cladding finish allows to remove the panel without the need to replace the door leaf. The quality and ergonomics of the Raptor door set combined with a wide range of cladding panels allows us to offer multi-functional doors that meet the requirements of the Architect and Investor

Cookie consent

This video is hosted by YouTube. By showing the external content you accept the terms and conditions of www.youtube.com.

*Your choice will be saved in a cookie until you have closed your browser.

Standard equipment:

  • door construction made of two sheets of galvanized steel – 1mm thick
  • corner frame made of 1.5 mm galvanized steel sheet, made without visible welds, powder painted in any color from the RAL palette
  • 6mm HDF removable, cladding panel compatible with the FINSA series
  • The main lock in class 6 key/key
  • The additional lock in class 6 key/turn
  • The cylinder with a unique key system class 6
  • Standard handle RAPTOR
  • Spyhole
  • Galvanized steel threshold, painted in the same color from the RAL palette as the door frame

At the customer's request, the door can be equipped with:

  • Internal or embracing frame
  • Natural wood or stone veneer
  • Decorative covering panels compliant with the door leaf finish
  • Keyless locks Yale Linus® Smart Lock

Technical parameters:

  • Burglar resistance RC3, according to PN-EN 1627
  • Mechanical strenght class 4, according to  PN-EN 1192
  • Acoustic insulation up to Rw=47 dB, according to PN-EN ISO 717-1: 2013-08
  • Air permeability U=1,3 W/m2K, according to ISO 10077-2:2012
  • Fire resistance class EI2 30 according to PN-EN 13501-2+A1: 2010
  • Smoke tightness class Sa, S200 according to PN-EN 13501
  • RAPTOR Brochure
  • RAPTOR Brochure(PDF, 1 MB)
  • Manufacturer's sample
  • Manufacturer's sample(PDF, 427 KB)
  • FINSA template
  • FINSA template(PDF, 3 MB)
