Access control
Number of users: More than 200,000 registered users
Number of faces: Up to 30,000 faces* with face liveness detection
Access rules: According to schedules and departments
Door control: Via external access control module | 1 REX button input, 1 open door sensor
Relay output: 1 relay on the external access control module rated up to 30 VAC / 5A
Wiegand input / output: 1 / 1 native port
Interconnectivity
Ethernet: 1 native 10/100 Mbps Ethernet port
USB: 1 USB 2.0 Host port
RS-485: 1 RS-485 port for communication between the external access control module and terminal
Wi-Fi: Wi-Fi connection module*
SIP intercom: Integrated G.711-compatible SIP intercom (Pro)*
Identification methods
Facial identification: Two 1080p Full HD cameras (visible light and infrared light)
Proximity reader*: MIFARE® or 125 kHz ASK or HID
Password: User identification through PIN and password
QR code: User identification through QR code
User interface
Display: 3.5” TFT color LCD display (320 x 480 px) with capacitive touchscreen
Integrated web software: Complete access control management from your browser
Audio: Built-in speaker and microphone
General characteristics
Dimensions (W x H x D): Terminal: 76.7 x 174 x 54.5 mm | External access control module: 52 x 52 x 22 mm
Equipment weight: Terminal: 240 g | External access control module: 35 g
Power input: External 12V 2A source
Ingress protection rating: IP65
Certifications
Markets: CE | FCC | UKCA | ISED*
* optional / available on select models
