ASSA ABLOY RR3000-Series Insulated Rigid Exterior Doors

ASSA ABLOY RR3000 ISO High-performance door

• Speed open/close: up to max. 2.1/0.7 m/s
• Wind Resistance Class 2-3 (EN 12424), DW >= 5000mm class 3, DW > 5000mm class 2
• Heat transfer coefficiency: door blade 1,4 W/m²K,
• Complete door min 1,5 W/m²K (depending on door size and specification)
• Temperature range: -20°C to +40°C (mounting side)
• Door Curtain: insulated sandwiched slats (50 x 200 mm) with thermally separated metal sheet trays, RAL 9006, painting in RAL colours as option
• Window slats optional, framed with anodized aluminium
• Control systems: Albany MCC standard, variable frequency drive with soft start / soft stop and absolute encoder
• Motor Power 1,1 KW
• Protection IP 55
• Mains Connections 3L/(N)/PE 380/400/415/440/480V, 50/60 Hz²
• Safety features: Light curtain as standard, Egress Break Release as option
• The door is designed according to the Workplace Directive of the UVV regulations and the harmonized CE Guidelines including the EN 13241-1.

Special:
Thermal Insulation, 50 mm thick insulated door panel. Minimal heat loss. No condensation. Outstanding U-Value. Smart Header Design: The design prevents door slats from touching one another as door opens and close for fast, smooth and quiet operations.
