PE360 - Mechanical mortise locks with microswitch for double leaf doors

PE360 mechanical mortise locks with microswitch are built for use on double-leaf emergency exit doors.

They are 1 locking point locks that are installed on the primary leaf. They are designed for installation on solid wooden doors.

They are equipped with a symmetrical latch and an automatic re-arming deadbolt, which ensures that the lock is always locked in two points. A trigger is installed on the deadbolt that allows the primary door leaf to be unlocked immediately when the secondary door leaf (counter-lock) is activated.

The door can only be opened from the outside using the cylinder, while on the inside, panic bar and cylinder always guarantee opening in case of emergency.

The double-action symmetrical latch allows use on right and left-hand doors. They are available with a 55 to 100 mm backset and have a flat forend.

The microswitch allows the lock to be monitored based on various options.

PE360 - Mechanical mortise locks with microswitch for double leaf doors

Type of lock	Mortise lock for solid wooden doors, designed for Europrofile cylinder with symmetrical latch and deadbolt
Scope	For double-leaf emergency doors
Installation	On primary leaf
Locking points	1 central
Reversible	With 24 mm forend: Yes (for right/left doors) With 20 mm forend: Available in 3 versions (reversible, for right doors, for left doors)
Compatible cylinders	Standard DIN cylinders
For fire-rated doors	Yes
Compatible panic exit devices	Suitable for use in combination with EN 1125 and EN 179 panic devices
Trigger on deadbolt	When the secondary leaf is operated, the primary leaf is also automatically unlocked
Microswitch	Yes
Monitoring options	Door status Bolt deadlocked Handle down Lock open Cylinder used Sabotage loop
Backset	55 mm \| 60 mm \| 65 mm \| 80 mm \| 100 mm
Distance	72 mm
Deadbolt lenght	20 mm
Forend lenght	20 mm \| 24 mm
Forend depth	3 mm
Handle spindle	8 mm \| 9 mm
Forend	Included \| Flat
