J-Series Single Door Panic Hardware

Variations

Variant 1

  • UNION
  • J-881-SIL (900mm)
  • J-881-W-SIL (1200mm)

Technical Attributes

  • Single point lateral locking touch bar
  • Max. door width 900mm/1200mm
  • Max. door height 2350mm
  • Anti-thrust steel deadlatch
  • Optional outside access device:
  • J-885-SIL

Certification

  • BS EN 1125
  • 3 | 7 | 6 | B | 1 | 3 | 2 | 2 | A | A



Variant 2

  • UNION
  • J-881TD-SIL (900mm)
  • J-881TD-W-SIL (1200mm)

Technical Attributes

  • Single point lateral locking touch bar
  • Low projection touch bar
  • Max. door width 900mm/1200mm
  • Max. door height 2350mm
  • Anti-thrust steel deadlatch
  • Integrated dogging device
  • Optional outside access device:
  • J-885-SIL

Certification

  • BS EN 1125
  • 3 | 7 | 6 | B | 1 | 3 | 2 | 2 | B | A



Variant 3

  • UNION
  • J-882-SIL (900mm)
  • J-882-W-SIL (1200mm)

Technical Attributes

  • Suitable for non-rebated double doors (will require 2 units)
  • 3 point locking
  • Max. door width 900mm/1200mm
  • Max. door height 2350mm
  • Anti-thrust steel deadlatch
  • Optional outside access device:
  • J-885-SIL

Certification

  • BS EN 1125
  • 3 | 7 | 6 | B | 1 | 3 | 2 | 2 | A | A



Variant 4

  • UNION
  • J-882TD-SIL (900mm)
  • J-882TD-W-SIL (1200mm)

Technical Attributes

  • Suitable for non-rebated double doors (will require 2 units)
  • 3 point locking
  • Low projection touch bar
  • Max. door width 900mm/1200mm
  • Max. door height 2350mm
  • Anti-thrust steel deadlatch
  • Optional outside access device:
  • J-885-SIL

Certification

  • BS EN 1125
  • 3 | 7 | 6 | B | 1 | 3 | 2 | 2 | B | A

1 of 8
