DC700G-FM

Variations

  • ASSA ABLOY-DC700G-FM
  • EN 3-6

Technical Attributes

  • Free-Motion® door closer with free-swing function starting from a door opening angle 0°
  • Certified in compliance with EN 1155/1154, size 3-6
  • Easy, initial door opening due to the rapidly decreasing opening force. When active, the free-swing function enables permanent
  • opening of the door without the resistance of the door closer
  • Door remains in free-swing mode until power supply is switched-off
  • For single action doors up to 1400mm wide
  • Fulfils barrier-free building requirements (EA / CEN TR 15894)
  • Can be used for left and right-handed doors
  • Suitable for fire and smoke protection doors
  • Adjustable closing speed, latching speed and backcheck
  • Variable adjustable closing force
  • Opening angle up to 160°
  • Hold-open variant available
  • Hold-open angle 130°
