Rim locks VERSO®CLIQ V136

With security link and external and internal cylinder set V933 - without keys

Overview of Advantages

• With robust bolt and solid lock case

Product description

• Available as mechanical or electromechanical version (V=)
• Visual locking display (green/red)
• Available in color: silver grey (FB=SGR) similar to RAL 9006, white (FB=WS) similar to RAL 9016 and brown (FB=BN) similar to RAL 8019
• Lock and lock case made of die-cast anti-corrosive zinc
• Solid brass bolt, double turn, 24 mm projection
• Massive steel security link, nickel-plated - for a minimum gap width
• Adjustable backset 60/70 mm
• Suitable for DIN left (S=R) or DIN right (S=L)
• For door leaf thicknesses from 36 to 45 mm
• For rebated and non-rebated doors
• Brass cylinder housing components
• Standard finish, satin nickel-plated (OF=MV)
• Tumbler elements with special wear-resistant alloy
• Optionally available for use in potentially-explosive atmospheres in Zone 1 (Ex II 2G) ATEX=II 2G Ex ib IIC T4 Gb

Scope of delivery

• 1 rim lock
• 1 V933 external and internal cylinder set
• 1 shim ring
• Lock case shims (2x 1 mm, 1x 3 mm and 1x 13 mm) for height adjustment up to 18 mm

Ordering Information

• Please include the desired color (FB=) as well as the DIN-door direction (S=) in your order
