DC700 G-FMS-K Cam-Motion free-swing door closer

For single-leaf doors up to size EN 6 (1,400 mm), lintel fitting, with integrated smoke detector in extended housing

Free-Motion^® compact door closer with Cam-Motion^® technology, free-swing function and integrated smoke detector, frame mounting hinge side

Product description

ASSA ABLOY compact Free-Motion^® door closer, free-swing function starting from a door opening angle ≥ 0°, with integrated smoke detector and power supply, in compliance to EN 1155
DIBT type approval as hold-open device Z-6.500-2364
Smoke switch with contamination indicator and alarm threshold monitoring
Integrated 230 V AC power supply
All components integrated in the door closer housing
Fulfils barrier-free-requirement (EA / CEN TR 15894)
Suitable for fire and smoke protection doors up to 1400 mm wide

Overview of Advantages

Easy, initial door opening due to the rapidly decreasing opening force. When active, the free-swing function enables permanent opening of the door without the resistance of the door closer
The door can be moved freely and, in case of a fire only, is closed automatically by the integrated smoke detector with the disconnection of the supply voltage.
Optical smoke detector after scattered light principle, status display on LED: operational mode, alarm, maintanance
Integrated power supply 230V AC
Connection possibility for manual release button – mandatory according to the DIBt approval in Germany – and additional smoke detector
Frame installation hing side, for left and right handed doors
Axis continuously height adjustable up to 14 mm
Opening angle up to 170°
Variable adjustable closing force
Thermodynamic valves for consistent performance
Effective latching speed range adjustable
Standard colours: silver EV1, white similar to RAL9016, stainless steel design
Customised finishes available on request

Characteristics for guide rail G795
