Access control
Number of users: More than 200,000 registered users
Number of fingerprints: Capacity for 6,000 / 10,000 / 50,000 / 100,000 fingerprints (depending on model)
Access rules: According to schedules and departments
Door control: Via external access control module | 1 REX button input, 1 open door sensor
Relay output: 1 relay on the external access control module rated up to 220 VAC / 5A
Wiegand input / output: 1 / 1 native port
Interconnectivity
Ethernet: 1 native 10/100 Mbps Ethernet port
USB: 1 USB 2.0 Host port
RS-485: 1 RS-485 port for communication between the external access control module and terminal
Wi-Fi: Wi-Fi connection module*
Identification methods
Fingerprint: 500 DPI optical fingerprint reader
Proximity reader*: MIFARE® or 125 kHz ASK or HID
Password: Numeric password
User interface
Display: 3.5” TFT color LCD display (320 x 480 px) with resistive touchscreen
Integrated web software: Complete access control management from your browser
General characteristics
Dimensions (W x H x D): Terminal: 81.2 x 184 x 51.8 mm | External access control module: 52 x 52 x 22 mm
Equipment weight: Terminal: 195 g | External access control module: 35 g
Power input: External 12V source
Power consumption: 1.92 W (160 mA) nominal
* optional / available on select models
