PED 300

Characteristics of PED 300

• Modular push bar type
• For Fire and Smoke applications
• High durability 200,000 cycles
• One central locking point
• For one or double leaf door up to 200 kg
• For all types of the door
• For doors up to 1200 mm width in standard
• For doors up to 1400 mm width in option
• Steel pulman latch in standard
• Dead latch in standard
• Steel or zinc alloy swing latch
• Zinc alloy cover 38 mm width
• Aluminium touch bar 1046 mm long
• Bar to be cut
• 73 mm projection
• HO function in option
• Micro switch version in option

 Accessories

• Outside trims Modular series
• Half cylinder (MKS possible)
• Various strikers
• Glass door installation kit

Finishes

Covers

• Black RAL 9005
• Silver RAL 9006
• S/Steel effect

Bars

• Red RAL 3000
• Silver RAL 9006
• S/Steel
