DC700G - FT - Door Closer - Surface Mounted
Door Closer DC700G-FT Cam-Motion®
Description:
- ASSA ABLOY Door Closer with Cam-Motion® technology, extended mounting plate and integrated latch bolt lock, extended guide rail with integrated escape door strike
- Suitable for retrofitting to fire doors with guide rail door closers and fastening using drilling template according to EN1154, Supplementary Sheet 1:2003-11
- In compliance with EN 1154, size EN3-6
- Escape door strike 332, tested in compliance with the German guidelines for electrical locking systems for doors along escape routes
- For single leaf doors, doors between 850mm - 1,200mm wide
Characteristics:
- Integrated escape door strike 332 in extended guide rail
- Integrated latch bolt lock 807 on extended mounting plate
- With 4m connecting cable
- Flush or surface installation of wiring possible
- Suitable for fire and smoke protection doors
- Suitable for left and right-handed doors
- Standard installation on hinge side
- Adjustable closing force
- Closing speed, latching speed and back-check continuously adjustable
- Thermodynamic valves for consistent performance
- Door closer axis height continuously adjustable by 14mm
- Standard colours: Silver EV1
